IEC Net filter 250VAC 10A FN9222-10-06 225uH

The FN 9222 IEC inlet filter combines an IEC inlet and mains filter with excellent filter attenuation in a small form factor. Choosing the FN 9222 product line brings you the rapid availability of a standard filter associated with the necessary safety acceptances. Standard IEC connector filters are a practical solution helping you to pass EMI system approval in a short time. A wide selection on amperage ratings, output connections, mounting possibilities and filters for medical applications are designed to offer you the desired solution

Component features:

• Exceptional conducted attenuation performance, based on chokes with high saturation resistance and excellent thermal behavior
• Rear/front or snap-in mounting
• Rated currents up to 10 A
• Excellent performance/size ratio
• Maximum continous operating voltage: 250 VAC, 50/60 Hz
• Operating frequency: DC to 400 Hz
• Approvals: ENEC, CQC
• Degree of protection: IP40
• Temperature Range (operation and storage): -25°C to +85°C (25/85/21)
• Designed corresponding to: UL 1283, CSA 22.2 No. 8 1986, IEC/EN 60939 (X to XX A, not Z types)
• MTBF @ 40°C/230 V (Mil-HB-217F):    3,040,000 hours
